Full Automatic Plastic Cup Printer

Full Automatic Plastic Cup Printer

SAMPLE APPLICATION AREA The sheet extruder is composed of extrusion, calendaring, traction and rolling. The main parts are abrasion resistant, resistant to corrosion, high-temperature resistant by high quality specially-treated. Low resistance force in die head extruding channel makes sheet...

Product Details

APPLICATION AREA



The equipment adopts relief printing two-side color words and patterns in plastic products surface with letterset method,and it can print six colors pattern in one time. It is widely used for printing yoghurt cup, ice-cream cup, fast-food bowl, and other cylindrical form or conical plastic product.



SAMPLES




TECHNICAL    PARAMETER

Model

TJYT-6A

Printing color

6 colors

Suitable printing material

PP, PS,   PET, HDPE , etc

Printing speed (depending on different cup)

150—200 pcs/min

Printing length

300mm

Printing area height

35-160mm

Printing area diameter

50-95mm

Printing cup diameter

65-120mm

Printing mould    roller diameter

100mm

Printing plate diameter

600mm

Printing angel

3°--13°

Max. forme on printing plate

3pcs

Cup mould roller

8pcs

Air    pressure

6-8 Bar

Max. air consumption

48 m³/h

Rated   power

15.8 kw

UV lamp power

6 kw x1

Aureole power

1 kw

Dimension

L4500*W2500*H2200 mm

Weight

About 4.50T



Company Brief Introduction

   Rui'an Litai Machinery CO.,LTD is founded in 2001. For more than 16 years, we focus on researching, developing, manufacturing and marketing on thermoforming machine, plastic cup production line, BOPS plastic thermoforming machine, mutil-layer PP/PS/PET sheet extruder, mould, etc. There are more than 72 countries and regions cooperating with us, such as USA, south Korea, Turkey, Canada, Russia, Kuwait, Iran, Brazil, Chile, Bolivia, Saudi Arabia, Peru, etc.

Company Certificate


Exhibition



Workshop



Partner



RELATED PRODUCT





FAQ

1.Are you a manufacturer?

Yes, we have been in making plastic thermoforming machineover 16 years.

2.What about the payment term ?

Mostly 30%T/T in advanced, the rest need be paid by TT before shipping

3.Machine adjustment and installation

We can send technicians go to customers' country for machine adjustment and installation

4.Guarantee time and after-sale

One year guarantee time, after one year , we have professional after-sales department providing best

service if customer has any problems.
