Coffee Cup Printer Machine

Coffee Cup Printer Machine

SAMPLE APPLICATION AREA The sheet extruder is composed of extrusion, calendaring, traction and rolling. The main parts are abrasion resistant, resistant to corrosion, high-temperature resistant by high quality specially-treated. Low resistance force in die head extruding channel makes sheet...

Chat Now

Product Details

APPLICATION AREA



The equipment adopts relief printing two-side color words and patterns in plastic products surface with letterset method,and it can print six colors pattern in one time. It is widely used for printing yoghurt cup, ice-cream cup, fast-food bowl, and other cylindrical form or conical plastic product.


TECHNICAL  PARAMETER

Model

TJYT-4A

TJYT-6A

Printing   color

4 colors

6 colors

Suitable   printing material

PP, PS, PET, HDPE , etc

PP, PS, PET, HDPE , etc

Printing   speed

(depending   on different cup)

100170 pcs/min

150200 pcs/min

Printing   length

300mm

300mm

Printing   area height

20-95mm

35-160mm

Printing   area diameter

55-95mm

50-95mm

Printing   cup diameter

60-120mm

65-120mm

Printing   mould  roller diameter

100mm

100mm

Printing   plate diameter

600mm

600mm

Printing   angel

3°--13°

3°--13°

Max. form   on printing plate

3pcs

3pcs

Cup mould   roller

8pcs

8pcs

Air  pressure

6-8 Bar

6-8 Bar

Max. air   consumption

48 m³/h

48 m³/h

Rated power

18 kw

15.8 kw

UV lamp   power

6 kw x1

6 kw x1

Aureole power

1 kw

1 kw

Dimension

L5500*W2300*H2200 mm

L4500*W2500*H2200 mm

Weight

About 4.20T

About 4.50T


Company Brief Introduction

   Rui'an Litai Machinery CO.,LTD is founded in 2001. For more than 16 years, we focus on researching, developing, manufacturing and marketing on thermoforming machine, plastic cup production line, BOPS plastic thermoforming machine, mutil-layer PP/PS/PET sheet extruder, mould, etc. There are more than 72 countries and regions cooperating with us, such as USA, south Korea, Turkey, Canada, Russia, Kuwait, Iran, Brazil, Chile, Bolivia, Saudi Arabia, Peru, etc.

Company Certificate


Exhibition



Workshop



Partner



RELATED PRODUCT






FAQ

1.Are you a manufacturer?

Yes, we have been in making plastic thermoforming machineover 16 years.

2.What about the payment term ?

Mostly 30%T/T in advanced, the rest need be paid by TT before shipping

3.Machine adjustment and installation

We can send technicians go to customers' country for machine adjustment and installation

4.Guarantee time and after-sale

One year guarantee time, after one year , we have professional after-sales department providing best

service if customer has any problems.
