Pvc Box Making Machine

1. Working stations adopt four-pillar structure. --more stable and more precise.2. Touch screen, PLC and servo motor adopt Delta brand from Taiwan.3.Material holder combine with the machine.It can save workshop space,easy to control..Forming station adopts savro motor system,more stable and efficient.4.Forming station adopts savro motor system,more stable and efficient.5.Heaters adopts “Elstein” from Germany, vacuum insulation cotton--save more energy.

Product Details

PVC Box Making Machine---Application:

TTF series thermoforming machine is forming, punching,cutting and stacking in one line. It is completely driven by servo motor, stable operation, low noise, high efficiency, suitable for producing plastic pvc box ,pvc plates, pvc tray etc. Easy to replace the mould, application to different specifications of products. Design the mould according to customer’s requirements,Applicable projects: the material of HIPS, PVC, PET, PS.


PVC Box Making Machine----Sample:

pvc box making machine

PVC Box Making Machine--- Technical Parameters

MAIN TECHNICAL PARAMETER

Model

TTF-520A

Forming Area

520mm x 400 mm

Forming Depth (Max.)

100mm

Sheet thickness

0.3-1.8mm

Forming Speed (Max.)

30times/min

Air pressure

 0.6-0.8mpa

Air consumption

 3 m³/min

Water consumption

 0.7 m³/h

Sheet width (Max.)

 570mm

Suitable Sheet

 PP, PS, HIPS, PET, PVC,etc.

Power supply

 AC 380V, 50Hz, Three-phase, Four-wire

Rated power

 110kw

Procedure

 Forming-punching-cutting-stacking

Dimension

 L11000*W4600*H2700mm

Weight

 About 8.0T

PVC Box Making Machine---Specification

specifics  520A.png
